25.6V 100Ah Solar Powerwall Lithium-ion Battery

◆24V 100ah Solar Powerwall Lithium-ion Battery can be connected in parallel, max 4P(Parallel). Please full discharge the battery pack before using it in parallel ◆Plated lron case, waterproof, anti-explosion ◆Connector protection, more stable for transportation ◆Wall mounted bracket for 24V 100ah LifePO4 battery pack is optional
Product serial number
M08S100BL
Product description
Parameters
Technical parameter

Powerwall Lithium-ion Battery

Solar energy 25.6v Solar Powerwall Lithium-ion Battery energy

storage battery series



● Wall mounted installation

● Deep cycle > 6000 times

● Low power consumption

● Easy and quick installation

● Well-designed, good-looking

● High safety lithium iron phosphate battery

● Plated lron case, waterproof, anti-explosion

Item
25.6V wall mounted LifePO4 battery pack, power wall solar energy storage system
Models
25.6V 100ah/200ah  (2.5kw, 5kw system)
Application
Home Appliances, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies
Warranty
5 years
Service
Relevant perameters or OEM/ODM service, just feel free to contact us! 24 hours online~



High Usable Ratio



● PCenerSys energy storage battery has high output

● Power and usable energy ratio can reach 95% usable ratio, environmental protection and saving.

● PCenerSys energy storage battery has 5/10kwh two types are optional.





Convenient Design



● High energy density battery, enabled PCenerSys power wall, Light weight.

● Compact size makes PCenerSys power wall easy to Handle.

● Wall mounted bracket is optional.

● Online customer service can guide the installation.





Beautiful Appearance



● The well-designed, classic black and white metal shell match makes the product look high-end and elegant.

● The product is installed on the wall like an interior decoration, high-end atmosphere.

● The product is small and light, and the unique design on the side makes the product easy to pick up.



Summary about 24V 200Ah Lithium ion Batteries as follows

+ 24V Lithium ion battery have 2 types of products, 24V 200Ah Lithium ion batteries and 24V 100Ah Lithium batteries, the operating voltage range is from 20V to 29.2V and the normal voltage is 25.6V

+ 25.6V Li ion battery includes smart BMS with max 100A continuous operating current at RT and smart protection functions.

+ LifePO4 battery with grade A deep cycle cells that improved the 24V batteries cycle life and the electrochemical performances.

+ 24V 200Ah Lithium ion Batteries has fireproof shell materials of iron.

+ 24V 200Ah Lithium ion batteries has quick plug connectors with good conductivity performance and easy to install.

+24V Lithium ion battery powerwall can wall mount battery in your home, its easy to install,and the batteries has black and white color,

+ 24V 200Ah Lithium ion battery are mainly used in energy storage application area, such as solar powerwell battery, energy storage battery and home solar energy storage system etc. . .

+ 25.6V Li ion battery can be charged and discharged with high current during operating.

+ 24V Li-ion battery can be used with 2 series and 8 parallel (max.) that can improve the batteries voltage and capacity, such as 48V 400Ah LifePO4 battery for energy storage system.

Keyword:
Powerwall Lithium-ion Battery
Powerwall Lithium-ion Battery products
Powerwall Lithium-ion Battery from China
We could not find any corresponding parameters, please add them to the properties table

Description

Parameters

Model

M08S100BL

M08S200BL

Nominal Capacity (Ah)

100

200

Nominal Energy (KWh)

22.45

25

Nominal Voltage (V)

25.6

25.6

Charge Voltage (V)

29.2

29.2

Discharge Cut-off Voltage (V)

20

20

Standard Charging Current(A)

20

40

Max.Continuous Charging Current (A)

100

100

Max.Continuous Discharging Curent (A)

100

100

Cycle Life

≥ 6000 times@80%DOD, 25°C

≥ 6000 times@80%DOD, 25°C

Operating Temp

Charge:0~60*C; Discharge: -20°C~65°C

Charge:0~60°C; Discharge: -20°C~65°C

Terminal

M8 Stud

M8 Stud

Size(L .xWxH) mm

500x 140x402

500x205x405

Net Weight (Kg)

~34.5

~61

Package Size (L xWXH) mm

677x507x385

677x507x385

Gross Weight (Kg)

~52.8

~75.5
