Solis inverter S6-EH3P12K-H-EU(21A) Three Phase | High Voltage
Solis Inverter S6-EH3P12K-H-EU(21A) Three Phase Hybrid Inverter
Product Description
The Solis inverter S6-EH3P12K-H-EU(21A) is a high-performance three-phase hybrid solar inverter designed for high-voltage battery systems (≥200V). It integrates advanced hybrid grid/off-grid operation, multi-MPPT technology, and three-phase balanced/unbalanced output capabilities. The product supports powerful expansion with up to 6 units in parallel, 4-channel MPPT inputs, and 160% PV input oversizing, delivering exceptional solar energy harvesting and power supply stability. With IP66 protection, seamless grid transfer within 10ms, strong overload capacity, and AI-powered smart control, it is an ideal solution for residential, commercial, and industrial scenarios requiring high reliability, flexible energy management, and long-term durability.
Key Advantages
High-Efficiency Solar Harvesting
Equipped with up to 4 MPPT inputs ideal for complex installations, supports 160% PV input oversizing to maximize solar energy utilization and power generation efficiency.
Strong & Stable Output Performance
160% off-grid overload capacity for 60s ensures stable startup of inductive loads, supports three-phase unbalanced output with each phase up to 50% rated power.
Seamless & Flexible Power Supply
Ultra-fast grid transfer within 10ms for uninterrupted power, compatible with grid-tied PV systems and supports grid-side generator access for weak grid scenarios.
Flexible System Expansion
Supports up to 6 units in parallel for large-capacity system expansion, with customizable battery backup level to guarantee uninterrupted power for critical loads.
PV-Only Off-Grid Operation
Supports off-grid working mode using solar power only, effectively reducing initial system investment cost while maintaining stable and reliable power supply.
Intelligent Control & Durability
AI-powered energy management and VPP-ready for higher savings, industrial-grade IP66 protection ensures stable operation in harsh environments.
Technical Specifications
| Solis inverter Models | 12K |
|---|---|
| Input DC (PV side) | |
| Recommended max. PV array size | 24 kW |
| Max. usable PV input power | 19.2 kW |
| Max. input voltage | 1000 V |
| Rated voltage | 600 V |
| Start-up voltage | 160 V |
| MPPT voltage range | 200 - 850V |
| Max. input current | 4 × 21A |
| Max. short circuit current | 4 × 31.5A |
| MPPT number / Max. input strings number | 4 / 4 |
| Battery | |
| Battery type | Li-ion |
| Battery voltage range | 120 - 700 V |
| Max. charge / discharge power | 12 kW |
| Max. charge / discharge current | 50 A |
| Communication | CAN/RS485 |
| Output AC (Grid side) | |
| Rated output power | 12 kW |
| Max. apparent output power | 12 kVA |
| Rated grid voltage | 3/N/PE, 380 V / 400 V |
| Rated grid frequency | 50 Hz / 60 Hz |
| Rated grid output current | 18.2 A / 17.3 A |
| Max. output current | 18.2 A / 17.3 A |
| Power factor | > 0.99 (0.8 leading - 0.8 lagging) |
| THDi | < 3% |
| Input AC (Grid side) | |
| Input voltage range | 304 - 437 V / 320 - 460 V |
| Max. input current | 27.3 A / 26.0 A |
| Rated grid frequency | 50 Hz / 60 Hz |
| Frequency range | 45 - 55 Hz / 55 - 65 Hz |
| Output AC (Back-up) | |
| Rated output power | 12 kW |
| Max. apparent output power | 1.6 times of rated power, 60s |
| Back-up switch time | < 10 ms |
| Rated output voltage | 3/N/PE, 380 V / 400 V |
| Rated frequency | 50 Hz / 60 Hz |
| Rated output current | 18.2 A / 17.3 A |
| THDv @ linear load | < 3% |
| Efficiency | |
| Max. efficiency | 97.85% |
| EU efficiency | 97.51% |
| BAT charged by PV max. efficiency | 98.31% |
| BAT charged / discharged to AC max. efficiency | 97.50% |
| Protection | |
| Anti-Islanding protection | Yes |
| Output over current protection | Yes |
| Short circuit protection | Yes |
| Surge protection | DC Type II / AC Type II (optional) |
| Integrated DC switch | Yes |
| DC reverse-polarity protection | Yes |
| Battery reverse protection | Yes |
| General Data | |
| Max. power per phase | 50% rated power |
| Dimensions (W × H × D) | 563 × 412 × 230 mm |
| Weight | 34.5 kg |
| Topology | Transformerless |
| Self-consumption (night) | < 25 W |
| Operating ambient temperature range | -25 ~ +60℃ |
| Relative humidity | 0 - 100% |
| Ingress protection | IP66 |
| Noise emission (typical) | < 46.9 dB(A) |
| Cooling concept | Natural cooling |
| Max. operation altitude | 4000 m |
| Grid connection standard | G98 or G99, VDE-AR-N 4105/VDE 0124, EN 50549-1, VDE 0126/JUTE C 15/VFR:2019, RD 1699/RD 244/UNE 206006/UNE 206007-1, CEI 0-21, C10/11, NRS 097-2-1, TOR, EIFS 2018/2, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530, MEA, PEA, EK18 |
| Safety / EMC standard | IEC/EN 61009-1-2, IEC/EN 61000-6-1/3 |
| Features | |
| PV connection | MC4 connector |
| Battery connection | Quick connection plug |
| AC connection | Quick connection plug |
| Display | LED indicator & Bluetooth + APP |
| Communication | CAN, RS485, Optional: Wi-Fi, Cellular, LAN |
Application Scenarios & Target Markets
Designed for large residential, commercial and global high-efficiency energy storage demands
Large Residential Homes
- Ideal for villas and large households with heavy power loads
- Supports 160% overload for stable operation of AC & pumps
- Seamless 10ms grid switching for uninterrupted power
Commercial Users
- Suitable for offices, shops and small industrial scenarios
- Three-phase unbalanced output for diversified loads
- High system efficiency reduces electricity costs
EPC Contractors
- Compatible with 21A high-power PV modules for easy installation
- Supports 160% PV oversizing to improve energy yield
- Compatible with existing grid-tied PV systems
Global Key Markets
- Widely used in Middle East, Europe, Asia and other regions
- High performance meets strict international standards
- Stable and reliable for various grid environments
Off-Grid & Remote Areas
- Ideal for remote homes, farms and areas with unstable grid access
- Provides reliable power supply with solar and battery integration
- Supports off-grid operation for continuous and independent energy use
Backup Power Applications
- Suitable for homes, offices and critical power demand scenarios
- Fast grid switching ensures uninterrupted operation of essential loads
- Provides reliable backup power during outages and grid failures
